Hall Effect Sensor (AH3031) , Hall Sensor, Magnetic Sensor, Speed Sensor, Encoder Sensor,

Hall Effect Sensor (AH3031) , Hall Sensor, Magnetic Sensor, Speed Sensor, Encoder Sensor,

Package Size 14.00cm * 8.00cm * 4.00cm Package Gross Weight 0.500kg These Hall-effect switch integrated circuits are mon;
Basic Info.
Model NO. AH3031
Theory Magnetic Sensor
Material Mixture
Usage Position Sensor, Liquid Level Sensor, Speed Sensor
Output Digital Sensor
Transport Package Carton
Specification ROHS, REACH
Trademark AHNJ
Origin Nanjing, China
HS Code 85423100
Production Capacity 100, 000, 000PCS/Year
Packaging & Delivery
Package Size 14.00cm * 8.00cm * 4.00cm Package Gross Weight 0.500kg
Product Description
These Hall-effect switch integrated circuits are monolithic integrated circuit consisting of a voltage regulator, hallvoltage generator, differential amplifier.
Features
Wide supply voltage range
Fast response time
Wide frequency and temperature range
Long operating life
Small size, convenient installing
Output compatible with all digital logic families
Typical Applications
Contactless switch
Position control
Speed measurement
Revolution detection
Isolation measurement
Brushless d. C motor
Automotive ignitor
Absolute maximum rating
ParameterSymbolValueUnit
Supply voltage VCC 24V
Magnetic flux density BUnlimitedmT
Output OFF voltage Vce 50V
Continuous output current IOL 50mA
Operating temperature range TA-40~125º C
Storage temperature range TS-55~150º C
Electrical Characteristics TA=25º C
ParameterSymbolTest conditions Type and ValueUnit
mintypmax
Supply voltageVCC4.5-24V
Output saturation voltageVOLIout=20mA B> BOP-200400mV
Output leakage currentIOHVout=24V B-0.110μ A
Supply currentICCVCC=Output open--10mA
Output rise time trRL=820Ω CL=20PF-0.12-μ S
Output fall timetfRL=820Ω CL=20PF-0.18-μ S

Hall Effect Sensor (AH3031) , Hall Sensor, Magnetic Sensor, Speed Sensor, Encoder Sensor,

Hall Effect Sensor (AH3031) , Hall Sensor, Magnetic Sensor, Speed Sensor, Encoder Sensor,

Hall Effect Sensor (AH3031) , Hall Sensor, Magnetic Sensor, Speed Sensor, Encoder Sensor,

Hall Effect Sensor (AH3031) , Hall Sensor, Magnetic Sensor, Speed Sensor, Encoder Sensor,
